| Handheld Wireless Mic System. Made by Line 6. (LP.L6XDR955)
X2 XDR955 is the wireless handheld microphone system that gives professional vocalists and presenters what they’ve always wanted: the clearest sound, the cleanest signal and total dependability. Heard loud and clear, X2 XDR955 features 24-bit digital conversion for a commanding tone that demands attention. Its extended frequency response of 10 Hz – 20 kHz, and extended dynamic range of over 115 dB, provide the full sound of a high-quality audio cable even at the outer reaches of its 300-foot range. Analog wireless systems are notorious for compressing their signals and for rolling off crucial high- and low-end frequencies. This produces typically "thin", "brittle" or "muffled" wireless sounds. X2 XDR955 never compresses its signal and ensures the full, rich and crystal-clear sound that professional vocalists need. X2 XDR955 provides extra signal protection with exclusive Line 6 dual-RF technology. The signal is shielded from static, jamming and dropouts commonly caused by cell phones, wireless networks and other unseen sources of RF energy, and the result is additional stability and dependability. A complete package, X2 XDR955 digital wireless system includes X2 XDH4 handheld transmitter microphone and the arena-ready X2 XDR4 digital receiver with rackmount kit and all applicable antennas and batteries. Free of complicated setup, just fire it up and go.
Specifications: Overall System Specifications: - Transmission Format: Line 6 proprietary digital audio transmission
- A/D-D/A Conversion: 24-bit delta sigma, 128 times oversampling
- Frequency Response: 10 Hz - 20 kHz
- Audio Dynamic Range: > 115 dB
- Distortion: 0.03% THD
- RF Carrier Frequency: 902 MHz to 928 MHz, FSK, dual frequency transmission
- Selectable Frequencies: Five
- RF Output Power: 15mw
- Audio Output Level: Unity gain with transmitter input
- Polarity: Positive voltage at input yeilds positive voltage at output
- Transmission Range: ~300 feet line-of-sight (may vary due to local conditions)
- FCC Approval: Part 15 approved, no user-license required
- Operating Temp. Range: –18° to +57° C (0° to +135° F)
X2 XDR4 Receiver Specifications - Output: 2.12V RMS (Unbalanced: 1.8K Ohm)
- Connectors: 1/4-inch unbalanced TRS output 1.8K-ohm impedance (tip= instrument voicing, ring= full bandwidth, sleeve= ground) XLR Balanced 600 ohm
- LED Display: Power On, RF, Channel, Diversity, Battery Life, Audio Level Meter
- Controls: Power On/Off, Channel Up and Down
- Dimensions (WxHxD): 1 3/4 inches W x 16 2/10 inches D x 7 1/2 inches H
- Power Requirements: Includes AC/DC adapter (9V DC 500mA)
- Weight: 2.5 lbs (with rack hardware and antennas installed)
- Housing: Polycarbonate, impact tested to 300 lbs
X2 XDH4 Transmitter Microphone Specifications - Controls: Power, Select
- LCD Readout: Backlit, custom function
- Dimensions: 6 1/4 inches x 1 1/2 inches (15.875 x 3.81 cm) without capsule
- Battery Life: Switching power supply, ~8 hours (2x AA alkaline)
- Weight: 12 1/2 oz. (with 2x AA batteries installed)
- Housing: Polycarbonate, impact-tested to 300 lbs.
- Microphone Type: Premium moving-coil dynamic
- Pattern: Cardioid
- Frequency Response: 50 Hz – 18 kHz
- Sensitivity: 2.5 mV/PA
- Maximum SPL: 144 dB
